High Gain Microwave Horn Antenna For Wireless Ptmp Communication

Name: High Gain Microwave Horn Antenna For Wireless Ptmp Communication
Brand: Famous
Price: 1 USD

Brand Name : Famous

Model Number : Horn Antenna

Certification : CE，ISO9001

Place of Origin : China

MOQ : 1 SET

Price : Negotiable

Payment Terms : T/T ， L/C

Packaging Details : Standard export packaging/customizable packaging

Name : Symmetrical Horn Antenna

Diameter of Mounting Pole : Φ51~Φ114 mm

Antenna Connection : Waveguide (special made by Dongguan Famous Precision) or SMA

Net Weight : 2.5kgs/5.5Ib

Material : UV stabilized PC, aluminum alloy

Wind survivability : 200 km/h

Wind loading : 200 km/h

Mechanical adjustment : ±25° elevation, ±25° azimuth

Pole compatibility : Ø40 to 60 mm

Weatherproofing : IP55

Contact Now

High Gain Microwave Horn Antenna for Wireless PtMP Communication

A Microwave Horn Antenna is a type of antenna used for transmitting and receiving microwave signals. It consists of a flared waveguide structure that gradually expands from a narrow aperture to a wider opening. This design allows the antenna to efficiently radiate or capture electromagnetic waves in the microwave frequency range.

One advantage of Microwave Horn Antennas is their wide bandwidth capability, allowing them to operate over a range of frequencies within the microwave spectrum. This makes them suitable for various applications, including radar systems, satellite communications, wireless networks, and scientific research.

Efficient PtMP horn antenna:

Wide frequency range 5.0-7.0GHz;
High isolation: 30° ;
With fast and easy installation waveguide;
High Gain;

Electrical performance:

	Frequency Range (GHz)	Gain (dBi)	Azimuth Beam Width -3dB	Elevation Beam Width -3dB	Azimuth Beam Width -6dB	Elevation Beam Width -6dB	Front/Back Ratio(dB)	VSWR	Polarization
30°	5.0-7.0	18	H21° V21°	H21° V21°	H30° V30°	H30° V30°	37	≤1.8	Dual-Linear
40°	5.0-7.0	16	H27° V27°	H27° V27	H40° V40°	H40° V40°	35	≤1.8	Dual-Linear
50°	5.0-7.0	14	H33° V33°	H33° V33°	H50° V50°	H50° V50°	33	≤1.8	Dual-Linear
60°	5.0-7.0	13	H41° V41°	H41° V41°	H60° V60°	H60° V60°	32	≤1.8	Dual-Linear
70°	5.0-7.0	11	H50° V50°	H50° V50°	H70° V70°	H70° V70°	30	≤1.8	Dual-Linear
80°	5.0-7.0	10	H60° V60°	H60° V60°	H80° V80°	H80° V80°	29	≤1.8	Dual-Linear
90°	5.0-7.0	9	H67° V67°	H67° V67°	H90° V90°	H90° V90°	28	≤1.8	Dual-Linear

Antenna Connection	Waveguide (special made by Dongguan Famous Precision) or SMA
Net Weight	2.5kgs/5.5Ib
Material	UV stabilized PC, aluminum alloy
Wind survivability	200 km/h
Wind loading	200 km/h
Mounting	Mechanical adjustment: ±25° elevation, ±25° azimuth Pole compatibility: Ø40 to 60 mm
Weatherproofing	IP55
